| Code No. | 1LF-LU550(LU8) | 1LF-LU460H(Heavy Duty) | 1LF-LU560H(Heavy Duty) |
| NO.of Bottom | 5(4+1) | 4 | 5(4+1) |
| Bottom No. | Standard LK500 ploughshares LK500M ploughshares are optional | Standard LK500 ploughshares LK500M ploughshares are optional | Standard LK500 ploughshares LK500M ploughshares are optional |
| Working Width Per Bottom | 33-50cm | 40-60cm | 40-60cm |
| Plough Point High | 182cm | 195cm | 195cm |
| Bottom to Bottom Size | 100cm | 120cm | 120cm |
| Plough Beam Specification | 140x140x12mm | 160x160x12mm | 160x160x12mm |
| Machine working width | 165-250cm | 160-240cm | 200-300cm |
| N.Weight | 2200kg | 2400kg | 2780kg |
| Power Required | 180-240HP | 200-260HP | 240-280HP |
